Capacity and Diameter

5gallon 14" diameter

8gallon 14" diameter

10gallon 14" diameter

16gallon 14" diameter

20gallon 18.25" diameter

30gallon 18.25" diameter

55gallon  22.5" diameter

85gallon 26" diameter

110gallon 30" diameter

Interior

Unlined, Rust Inhibitor, or Lined

Linings available:

L-1 Clear/Non-Pigmented Phenolic (Gold)

L-5X Pigmented Phenolic (Olive Drab)

L-15 Pigmented Phenolic Epoxy Lining(Dark Brown or Dark Red)

L-31 Clear Phenolic Epoxy (Gold)

L-35 Pigmented Epoxy Phenolic (Buff)

L-40 Clear/Non-Pigmented Epoxy Phenolic Size Coat and Rust Inhibitor (Clear)

Exterior

Black, White, Blue, Red, Orange, Yellow, Green, Grey, Silver, as well as many other custom colors

Closures

Trisure 2" and 3/4" Steel Flange with Steel, Poly, or Nylon Plugs

Rieke 2" and 3/4" Steel or Nylon Flange with Steel, Poly, or Nylon Plugs

Plug Gaskets available: Buna, White EPDM, Poly, Poly Irradiated, Teflon, or Viton

Ring options: 12Gauge with 5/8 Nut/Bolt(UN), Standard 5/16" Nut/bolt(NON-UN), Lever Lock, and Lever Latch

Construction and Performance

20 Gauge to 16 Guage

Standard or ISO W-Hoop

UN Certified for Packaging Groups I(X-Rated), II (Y-Rated), and III(Z-Rated) For Liquids and Solids
